Audio-Technica ATW-A49 UHF Wide-band Directional LPDA Antenna
Product Highlights:
- Enhanced signal pickup
- Wideband (440-900 MHz) operation
- 6 dB RF gain improvement
- 90 degree beamwidth
- Rugged industrial grade copper-clad epoxy fiberglass construction
- Low-loss BNC connector positioned to minimize cable strain
- Audio-Technica ATW-A49A UHF Wide-band Directional LPDA Antenna
Audio-Technica ATW-A49 UHF Wide-band Directional LPDA Antenna
Audio-Technica ATW-A49A UHF Wide-band Directional LPDA Antenna
The ATW-A49 is a set of wideband directional log periodic dipole array (LPDA) antennas designed for enhanced signal pickup for UHF wireless systems operating throughout a wide band range (440-900 MHz). Supplied in pairs, these directional antennas are ideal for extending the operating range and reliability of diversity UHF wireless systems. When used in a multi-system application with appropriate antenna distribution systems, they eliminate the need for multiple frequency-specific antennas. Compatible with virtually all UHF wireless receivers, the ATW-A49 provides a directional coverage pattern with a typical beamwidth of 90 degrees. Each antenna offers approximately 6 dB of RF gain improvement over standard receiver whip antennas and is designed to match standard 50 ohm impedance transmitter outputs and receiver inputs. High-quality low-loss BNC-type connectors are positioned to minimize RF cable strain even when used with large-diameter cables. Designed to mount to a standard 5/8"-27 microphone thread fitting, the antenna includes an adjustable mount to allow for horizontal and vertical adjustment for accurate positioning. Constructed of industrial-grade copper-clad epoxy fiberglass, the antennas are engineered to resist the effects of corrosion, UV degradation and vibration, providing long life and stable performance under difficult operating conditions. The antennas are supplied completely assembled.
| ATW-A49A Specs |
|---|
| Antenna & Distribution |
|---|
| Polarization |
100°, 3 dB beam width |
| Frequency Range |
470 to 950 MHz |
| Impedance |
50 ohms typical |
| Gain |
6 dBi typical |
| Connections |
BNC-J |
