| General Specification |
|---|
| Power: |
DC 7.28 V (Battery Operation)
DC 12 V (AC adapter operation) |
| Power Consumption: |
19 W (with LCD/HDMI/SDI ON) |
| Operating Temperature: |
0 °C to 40 °C (32°F to 104°F) |
| Operating Humidity: |
10% to 85% (relative humidity) |
| Storage Temperature: |
-20 °C to 60 °C (-4°F to 140°F) |
| Weight: |
Body: Approx. 1.2 kg (2.65 lb)
(excluding accessories)
Shooting: Approx. 2.05 kg (4.52 lb)
(with accessories) |
| Dimensions: |
135 mm (W) x 133 mm (H) x 170 mm (W)
(excluding protrusions and accessories)
(5-5/16 inches x 5-1/4 inches x 6-11/16 inches) |
| Camera Unit |
|---|
| Image Sensor: |
Super 35 mm, MOS sensor |
| Number of Pixels: |
Total pixels:
Approx. 20.49 megapixels, 6340 (H) x 3232 (V)
Effective pixels:
Approx. 17.25 megapixels, 5720 (H) x 3016 (V) |
| Sensor Area and Max Frame Rate: |
S35: 4K/UHD 60 fps/50 fps
2K/HD 120 fps/100 fps
4/3": 2K/HD 240 fps/200 fps |
| Latitude: |
14 stop |
| Log: |
V-Log |
| Gamma: |
eV-Look Gamma (2 types)
Video Gamma
Hybrid Log Gamma (HLG) |
| Gamut: |
V-Gamut (V-Log) |
| EI Settings: |
[ISO] mode: NATIVE ISO: 800, 2500
800 Base: 200 to 2000
2500 Base: 1000 to 25600
[dB] mode: (Normal) -12 dB to 8 dB
(High) -8 dB to 20 dB |
| Shutter Speed: |
[deg] mode: 1.0 deg to 358 deg (0.5 deg step)
12 presets
[sec] mode: 1/24.1 sec to 1/8000 sec (23.98p)
12 presets |
| Color Temp: |
ATW, AWB, 2000 K to 15000 K ±10.0 GMg
12 presets |
| Lens Mount: |
EF mount |
| Image Stabilization: |
Electric Image Stabilization (EIS) |
| Auto Focus: |
One push auto focus |
| ND Filter: |
CLEAR, 0.6ND, 1.2ND, 1.8ND, Electrical driven |
| IR Cut Filter: |
USER assignable IR shooting (filter ON/OFF) |
| Memory Card Recorder |
|---|
| Recording Media: |
SDHC memory card (4 GB to 32 GB)
SDXC memory card (32 GB to 128 GB)
UHS- /UHS- UHS Speed Class3 is supported,
Video Speed Class V90 is supported |
| Recording Slot: |
SD memory card slot x 2 |
| Recording Resolution: |
4096 x 2160 (4K), 3840 x 2160 (UHD),
2048 x 1080 (2K), 1920 x 1080 (FHD),
1280 x 720 (HD) |
| Recording System Frequency: |
59.94p, 50p, 29.97p, 25p, 24p, 23.98p
59.94i, 50i (AVCHD only) |
| 2slot Functions: |
Simul Rec, Relay Rec, Loop Rec*1,
Background Rec*1 |
| Other Rec Functions: |
Pre Rec, Interval Rec*1, One Shot Rec*1 |
| Digital Video |
|---|
| Quantizing: |
MOV: 4:2:2 10 bit/4:2:0 8 bit
AVCHD: 4:2:0 8 bit |
| Video Compression Format: |
H.264/MPEG-4 AVC High Profile |
| Digital Audio |
|---|
| Recording Audio Format: |
MOV: 48 kHz/24 bit, 2 CH, Linear PCM
AVCHD: 48 kHz/16 bit, 2 CH, Dolby Audio ™ |
| Headroom: |
18 dB/20 dB (menu switchable) |
| Video Output |
|---|
| SDI OUT: |
BNC x 1, SDI REC REMOTE is supported
0.8 V [p-p], 75 Ω , 4K (6G), HD (3G/1.5G)
Output format (4:2:2 10 bit):
- 4096 x 2160: 29.97p, 25p, 24p, 23.98p
- 3840 x 2160: 29.97p, 25p, 24p, 23.98p
- 1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p,
29.97PsF, 25p, 25PsF, 24p, 24PsF,
23.98p, 23.98PsF
- 1280 x 720p: 59.94p, 50p
RAW* output format (10 bit):
- 5760 x 3072: 29.97p, 25p, 24p, 23.98p
- 4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p,
23.98p |
| HDMI: |
HDMI x 1, TypeA, HDMI REC REMOTE is supported,
Viera Link is NOT supported
Output format (4:2:2 10 bit):
- 4096 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
- 3840 x 2160: 59.94p, 50p, 29.97p, 25p, 24p, 23.98p
- 1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p,
25p, 24p, 23.98p
- 1280 x 720: 59.94p, 50p
- 720 x 480: 59.94p
- 720 x 576: 50p
Output format (4:2:0 8 bit):
- 4096 x 2160: 59.94p, 50p
- 3840 x 2160: 59.94p, 50p |
| Audio Input/Output |
|---|
| Internal Mic: |
Stereo microphone |
| INPUT1/2: |
XLR (3-pin) x 2 (INPUT1/2), input high impedance,
LINE/MIC/MIC +48 V (menu switchable)
MIC: 40 dBu/ 50 dBu/ 60 dBu (menu switchable)
LINE: +4 dBu/0 dBu (menu switchable) |
| SDI OUT: |
Linear PCM 2 CH |
| HDMI: |
Linear PCM 2 CH |
| PHONES: |
3.5 mm stereo mini jack x 1 |
| Speaker: |
20 mm diameter, round x 1 |
| Other Input/Output |
|---|
| TC IN/OUT: |
BNC x1 for IN/OUT (menu switchable)
IN: 1.0 V [p-p] to 4.0 V [p-p], 10 kΩ
OUT: 2.0 V [p-p] ±0.5 V [p-p], low impedance |
| LCD: |
40-pin (Dedicated) |
| REMOTE: |
2.5 mm Super Mini Jack |
| USB 2.0 (HOST): |
Type-A, 4-pin for Wireless Module (AJ-WM50) |
| EF Mounting Contact: |
8-pin |
| DC IN 12 V: |
DC 12 V (10.5 V to 13.5 V) EIAJ type 4 |
| LCD Monitor |
|---|
| Size: |
3.5-type LCD monitor (approx. 1,150,000 dots)
Touch panel
(MENU control, Shooting assist functions) |
| Switches: |
MIRROR (OFF, B/T, ROTATE) |
| Hand Grip |
|---|
| Mounting Mechanism: |
One touch rotatable/Detachable |
| Switches: |
REC, MENU/IRIS dial, User switch x 2 |
| Included Accessories |
|---|
| Accessories: |
Battery (5900 mAh), Battery charger, AC adapter,
AC cable, Shoulder strap, Microphone holder,
Microphone holder adapter, LCD monitor (with
hood and mounting attachment), Handle, Grip,
Grip belt, Mout cap |
