Core SWX NANO Micro 50 Lithium-Ion Battery (Gold Mount)
Product Highlights:
- 49Wh Lithium-Ion Gold Mount Battery
- Supports up to 6A Continuous Draw
- D-Tap & 5V USB Outputs
- 4-Stage LED Status Gauge
- Ultracompact, Travel-Friendly Size
- Core SWX NANO Micro 50 Lithium-Ion Battery (Gold Mount)
- Limited 2-Year Manufacturer Warranty
NOT INCLUDED
Core SWX NANO Micro 50 Lithium-Ion Battery (Gold Mount)
Core SWX NANO-G50 NANO Micro 50 Lithium-Ion Battery (Gold Mount)
Ultracompact, yet powerful, and ideal for devices from cameras to monitors, the Gold mount NANO Micro 50 Lithium-Ion Battery from Core SWX powers your gear while keeping the weight to a minimum. The battery features 14.8V output to power your professional devices, and it supports up to 6A continuous draw.
The battery provides one unregulated D-Tap output port, and it also features one 5V USB Type-A port to charge smaller devices such as a smartphone. The 4-stage LED gauge shows the battery level status. The NANO Micro can be charged on a Core SWX or most third-party Gold mount chargers, as well as via the D-Tap port.
The NANO Micro features a 14.8V, 49Wh capacity suitable for lighter camera powering applications like RED KOMODO and Canon Cinema builds.
A 4-stage LED gauge displays the battery power level.
Power equipment using one D-Tap output.
One 5V USB Type-A output can be used to charge smaller equipment such as a smartphone.
The 14.8V, 49Wh capacity allows for the packs to be transported carry-on without restrictions under IATA, ICAO, and UN regulations. However, always check with your carrier before flying with Lithium batteries. The packs have been UN tested and certified, passing UN38.3 certification.
| Core SWX NANO Micro 50 Specs |
|---|
| Mount / Series Type |
Gold Mount
|
| Chemistry |
Lithium Iron Phosphate
|
| Battery Capacity |
3300 mAh / 49 Wh
|
| Output Voltage |
14.8 VDC
|
| Maximum Load |
6 A
|
| Accessory I/O |
1 x D-Tap Output
1 x USB Type-A Output
|
| USB Output |
5 V
|
| Dimensions (W x H x D) |
3.93 x 2.82 x 1.49" / 9.98 x 7.16 x 3.78 cm
|
| Weight |
12.8 oz / 363 g
|
| Packaging Info |
|---|
| Package Weight |
0.84 lb
|
| Box Dimensions (LxWxH) |
5.4 x 3.6 x 2.3"
|
