Netgear AV Line M4250 GSM4230P 24-Port Gigabit PoE+ Compliant Managed Network Switch with SFP (300W)
Product Highlights:
- 24 x Gigabit Ethernet PoE+ Ports
- 4 x Gigabit SFP Ports
- 60 Gb/s Switching Capacity
- 44.64 Mpps Forwarding Rate
- 1.8 GHz ARM Cortex-A57 Quad-Core CPU
- 2GB RAM
- Rack-Mountable Design
- 300W Power Budget
- AVB Support
- Netgear AV Line M4250 GSM4230P 24-Port Gigabit PoE+ Compliant Managed Network Switch with SFP (300W)
- Power Cord
- Console USB Type-C and RJ45-DB9 Cables
- 2 x Rack-Mounting Standard Brackets & Screws
- 2 x Recessed Mounting Brackets & Screws
- Rubber footpads for Tabletop Installation
- Limited Lifetime Warranty
- 90-Day Technical Support via Phone and Email
Netgear AV Line M4250 GSM4230P 24-Port Gigabit PoE+ Compliant Managed Network Switch with SFP (300W)
Netgear GSM4230P-100NAS AV Line M4250 GSM4230P 24-Port Gigabit PoE+ Compliant Managed Network Switch with SFP (300W) Engineered for AV over IP Excellence Developed with insights from AV professionals, the Netgear M4250 GSM4230P AV Line Managed Switch is purpose-built for 1G AV over IP applications. It features 24 PoE+ compliant RJ45 ports, all rear-facing for streamlined rack installations, supported by a 300W power budget. In addition, four Gigabit SFP uplink ports enable clean and efficient connectivity. With pre-configured settings, the switch is ready to perform straight out of the box.
Tailored for AV Installations
- Plug-and-Play AV Integration: NETGEAR’s IGMP Plus ensures multicast traffic is automatically configured for most AV over IP systems.
- Intuitive AV Interface: A purpose-built, browser-based interface provides color-coded port profiles, simplifying configuration for AV technicians.
- Audio Protocol Support: Quickly assign port profiles for popular audio standards including Dante, AES67, and AVB.
- Integrated Video Profiles: Configure ports for NVX, SVSI, Q-SYS, or Dante video protocols with ease.
Flexible and Secure Mounting Options
- Compact Rack Design: A 1RU, 7.9” deep chassis with all connectivity at the rear ensures a tidy and professional rack installation.
- Reversible Mounting Option: Easily reverse-mount with front-facing ports and recessed placement for cable protection.
- Universal Mounting Support: Includes M5 and M10 threaded holes for secure installation outside of traditional rack systems.
Comprehensive Network Capabilities
- Layer 2/Layer 3 Switching: Built on a consistent switching architecture shared across all M4250 models, supporting both layer types.
- Versatile Management Options: Control the switch via web GUI, console, Telnet, or SSH to suit various workflows.
- Full Network Feature Set: Supports static, RIP, and PIM routing
| Netgear GSM4230P-100NAS Specs |
|---|
| Protocols |
|---|
| Layer Services Supported |
Layer 2, Layer 3
|
| Supported Protocols |
Link Aggregation
Port Mirroring
DHCP Server
IGMP Snooping
IPv6
IPv4
|
| Jumbo Frames Support |
12,000 Bytes
|
| MAC Address Table Size |
16K
|
| Security |
|---|
| Security Features |
DHCP Snooping
DoS Attack Prevention
RADIUS Authentication
Storm Control
|
| Performance |
|---|
| Forwarding Rate |
44.64 Mpps
|
| Switching Bandwidth |
60 Gb/s
|
| Packet Buffer |
16 Mb
|
| Computer |
|---|
| CPU |
Quad-Core: Up to 1.8 GHz Cortex A57
|
| Memory |
2 GB
|
| Electrical |
|---|
| PoE per Port |
30 W
|
| PoE Power Budget |
300 W
|
| Power Draw |
401.00 W (Max)
23.4 W (Standby)
|
| Power Supply Type |
Internal
|
| General |
|---|
| Certifications |
No
|
| Cooling System |
Fan/Passive Combo (Noise Level 34 dB)
|
| Indicator Lights |
Yes
|
| Rack Mountable |
Yes 1 U
|
| Dimensions |
17.3 x 10.1 x 1.7" / 440 x 257 x 43.2 mm
|
| Weight |
9.5 lb / 4.3 kg
|
| Packaging Info |
|---|
| Package Weight |
12.81 lb
|
| Box Dimensions (LxWxH) |
21 x 12.7 x 4.7"
|
