| General |
|---|
| Mass |
Approx. 3.6 kg (body only without lens, VF, Mic)
Approx. 7 lb 15 oz (body only without lens, VF, Mic) |
| Dimensions (W x H x D) |
150 x 269 x 332 mm (excluding protrusions, body only)
6 x 10 5/8 x 13 1/8 inches (excluding protrusions, body only) |
| Power Requirements |
DC 12 V (11 V to 17.0 V) |
| Power Consumption |
Approx. 22 W (while XAVC recording, color LCD on)
Approx. 24 W (while XAVC recording, CBK-VF02 viewfinder and color LCD on) |
| Operating Temperature |
0° C to 40° C (32° F to 104° F) |
| Storage Temperature |
-20°C to +60°C (-4°F to +140°F) |
| Continuous Operating Time |
Approx. 240 min with BP-GL95 |
| Camera Section |
|---|
| Imager |
3-chip 2/3-type "Exmor" Full HD CMOS |
| Effective Picture Elements |
1920 (H) x 1080 (V) |
| Optical System |
F1.4 prism system |
| Built-in Optical Filters |
1: Clear, 2: 1/4ND, 3: 1/16ND, 4: 1/64ND |
| Shutter Speed (Time) |
1/60 sec to 1/2,000 sec + ECS (Extended Clear Scan) |
| Shutter Speed (Slow Shutter (SLS)) |
2, 3, 4, 5, 6, 7, 8, 16-frame accumulation |
| Slow & Quick Motion |
720p: Frame rate selectable from 1 fps to 60 fps
1080p: Frame rate selectable from 1 fps to 60 fps |
Sensitivity
2000 lx, 89.9% reflectance) |
F12 (typical) (1920 x 1080/59.94i mode)
F13 (typical) (1920 x 1080/50i mode) |
| Minimum illumination |
0.013 lx (typical) (1920 x 1080/59.94i mode, F1.9,
+42 dB gain, with 64-frame accumulation) |
| White Balance |
Preset (3200K), Memory A, Memory B/ATW |
| Gain Selection |
-3, 0, 3, 6, 9, 12, 18, 24, 30, 36, 42 dB |
| S/N Ratio |
62 dB (Y) (Noise Suppression On) |
| Horizontal Resolution |
1,000 TV lines or higher (1920 x 1080i mode) |
| Digital Extender |
x2, x3, x4 |
| Audio |
|---|
| Frequency Response |
20 Hz to 20 kHz (±3 dB or less) |
| Dynamic Range |
90 dB (typical) |
| istortion |
0.08% or lower (-40 dBu input level) |
| Headroom |
20 dB (factory default) (20, 18, 16, 12 dB), EBUL |
| Recording format (Video) |
|---|
| XAVC Intra (XAVC-I mode): |
- 1920 x 1080: 59.94i, 50i, 29.97p, 25p, 23.98p
- 1280 x 720: 59.94p, 50p |
| XAVC Long (XAVC-L 50 mode): |
- 1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 23.98p
- 1280 x 720: 59.94p, 50p |
| XAVC Long (XAVC-L 35 mode): |
1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 23.98p |
| XAVC Long (XAVC-L 25 mode): |
- 1920 x 1080: 59.94i, 50i |
| MPEG HD422: |
- 1920 x 1080: 59.94i, 50i, 29.97p, 25p, 23.98p
- 1280 x 720: 59.94p, 50p, 29.97p, 25p, 23.98p |
| MPEG HD420: |
- 1920 x 1080: 59.94i, 50i, 29.97p, 25p, 23.98p
- 1440 x 1080: 59.94i, 50i
- 1280 x 720: 59.94p, 50p |
| MPEG IMX: |
- 720 x 486: 59.94i
- 720 x 576: 50i |
| DVCAM: |
- 720 x 480: 59.94i
- 720 x 576: 50i |
| Recording Format (Audio) |
|---|
| XAVC Intra: |
LPCM 24 bits, 48 kHz, 4 channels |
| XAVC Long: |
LPCM 24 bits, 48 kHz, 4 channels |
| MPEG HD422: |
LPCM 24 bits, 48 kHz, 4 channels |
| MPEG HD: |
LPCM 16 bits, 48 kHz, 4 channels |
| MPEG IMX: |
LPCM 16/24 bits, 48 kHz, 4 channels*2 |
| DVCAM: |
LPCM 16 bits, 48 kHz, 4 channels |
| Recording Format (Proxy Video) |
|---|
| XAVC Proxy: |
AVC/H.264 Main Profile 4:2:0 Long GOP, VBR
1280 x 720, 9 Mbps (Target Rate)
1280 x 720, 6 Mbps (Target Rate)
640 x 360, 3 Mbps (Target Rate)
480 x 270, 1 Mbps, 500 kbps (Target Rate) |
| Recording Format (Proxy Audio) |
|---|
| XAVC Proxy: |
AAC-LC, 128 kbps, 2 channels |
| Input/Output |
|---|
| Genlock Input |
BNC (x1), 1.0 Vp-p, 75 Ω, unbalanced |
| Timecode Input |
BNC (x1), 0.5 V to 18 Vp-p, 10 kΩ |
| SDI Input |
SMPTE ST292/ST259 standard compliant, 4-channel audio
1.5G
Poolfeed Recording (upto 1080 59.94i) |
| Audio Input |
CH1/CH2: XLR-type 3-pin (female) (x2), Line/Mic/Mic/+48V selectable
LINE: +4, 0, -3 dBu
AES/EBU: AES3 compliant
MIC: -70 dBu to -30 dBu |
| Mic Input |
XLR-type 5-pin, female: -70 dBu to -30 dBu |
| WRR (Wireless Microphone Receiver) |
D-sub 15-pin
Analog CH1: -40 dBu
Digital CH1/CH2: -40 dBFS |
| SDI Output |
Output 1/2: BNC (x2), 0.8 Vp-p,
unbalanced, 3G HD/1.5G HD/SD selectable,
SMPTE ST424/ST425 Level-A/B, ST292/ST259 standard compliant,
4-channel audio |
| Video Output |
BNC, SD analog composite/HD-Y selectable |
| Audio Output |
XLR-type 5-pin, male, +4/0/-3 dBu (balanced) |
| Timecode Output |
BNC, 1.0 Vp-p, 75 Ω |
| Earphone Output |
Stereo mini jack (x1)
-11 dBu reference level output, maximum monitor volume, 16 Ω load |
| Speaker Output |
Monaural, 300 mW output |
| DC Input |
XLR-type 4-pin, male, 11 V to 17 V DC |
| DC Output |
Round type 4-pin, 11 V to 17 V DC, 1.8 A maximum rated current |
| Lens |
12-pin, lens power source (11 V to 17 V DC, 1.0 A maximum rated current) |
| Remote |
8-pin |
| Light |
2-pin |
| Camera Adaptor |
D-sub, 50-pin (x1) |
| Ethernet |
RJ-45 (x1), 100BASE-TX: IEEE 802.3u, 10BASE-T: IEEE 802.3 |
| USB |
USB 3.0/2.0 4-pin (type A), USB2.0 4-pin (type B), USB2.0 4-pin (type-A) |
| HDMI |
A type, 19-pin (x1) |
| Viewfinder |
20-pin IF for HDVF Series Viewfinder, and 26-pin IF for CBK-VF02, HDVF-L750 |
| Monitoring |
|---|
| Viewfinder |
PXW-X400: Option
PXW-X400KC/PXW-X400KF: 3.5-inch*2 type color LCD monitor:
960 (H) x 540 (V), Quarter HD Size*4 |
| Built-in LCD Monitor |
Color LCD, Screen size: 8.8 cm (3.5 inch) diagonal,
Aspect ratio: 16:9, Number of pixels: 960 (H) x 540 (V)
for Video display, Audio level, TC, battery
and media remaining capacity |
| Other Functions |
|---|
| Built-in Speaker |
(x1) |
| Media SxS Card Slots |
Form factor: Express Card/34, Number of slots: 2,
Connector: PCMCIA Express Card compliant,
Write rate: 50 Mbps or higher,
Read rate: 50 Mbps or higher |
| Media SD Card Slots |
Proxy (1), Utility (1) |
| GPS |
Yes |
| Built-in Network Module |
Yes |
| NFC*3 |
Yes |
| Media |
|---|
| High resolution Video/Audio |
SxS card
XQD card (with XQD ExpressCard Adapter, QDA-EX1)
SDXC card (with XQD ExpressCard Adapter, MEAD-SD02) |
| Proxy Video/Audio and Utility |
SDXC/SDHC |
| Supplied Accessories |
|---|
Shoulder strap (1)
Cold shoe kit (1)
Operation Guide (1)
Operation Manual (CD-ROM) (1)
USB wireless LAN module (IFU-WLM3) (1) |
| PXW-X400KC/PXW-400KF only: |
Viewfinder (1)
Stereo microphone (1)
Wind-screen (1)
Lens mount cap (1)
Flange back adjustment chart (1)
PXW-X400KC: Manual focus lens (1)
PXW-X400KF: Auto focus lens (1) |
*1: PXW-X400KF Auto focus capability will be available in June, 2016.
*2: Viewable area, measured diagonally.
*3: NFC (Near Field Communication) will be supported with future firmware upgrading.
*4: Equivalent to CBK-VF02. |
