Description
Clear-Com FreeSpeak II (1.9 or 2.4GHz) 20 Station Digital Wireless Intercom System
The FSII-BASE-II is a base station (includes 25 licenses) for the wireless FreeSpeak II 1.9GHz and 2.4GHz active transceiver and beltpacks with four 2-wire analog partyline connections, four 4-wire audio connections and four digital displays with soft keys. The base station can operate a mix of up to (25) 1.9GHz and/or 2.4 GHz beltpacks on a single system. The base station can be used in Main Station mode with Talk and Call soft keys or as a Headset Station for communication and monitoring from the panel. The base station's digital displays allow easy system configuration directly from the base station or through the browser-based Core Configuration Manager tool.
The FSII-BASE-II is a base station (includes 25 licenses) for the wireless FreeSpeak II 1.9GHz and 2.4GHz active transceiver and beltpacks with four 2-wire analog partyline connections, four 4-wire audio connections and four digital displays with soft keys. The base station can operate a mix of up to (25) 1.9GHz and/or 2.4 GHz beltpacks on a single system. The base station can be used in Main Station mode with Talk and Call soft keys or as a Headset Station for communication and monitoring from the panel. The base station's digital displays allow easy system configuration directly from the base station or through the browser-based Core Configuration Manager tool.
Clear-Com FreeSpeak II Digital Wireless Intercom System with 20 Beltpacks and Headsets, 4 Remote Antennas, 20 Batteries, (4) 5 Bay Chargers


Clear-Com FreeSpeak II Digital Wireless Intercom System with 20 beltpacks and Headsets, 4 Remote Antennas, 20 Batteries, (4) 5 Bay Chargers
Technical Specs
FreeSpeak II Base II | |
---|---|
Base-to-Beltpack Frequency Response: | 100Hz - 7.1kHz |
No. of Beltpacks per Base Station: | 25 |
No. of Transceiver/ Antennas Supported by Base: | 10 |
No. of Active Transceiver Ports: | 2, one port can remotely power up to 1 FSII splitter or 1 FSII transceiver |
PC Programming Port: | 2 LAN RJ45 |
Relay Port: | DB15, supports 1 set of relays and 2 GPI |
Partyline A ,B,C,D (each): | XLR-3F, on/off termination switch, Clear-Com and RTS compatible |
Partyline Power On/Off: | A/B, C/D paired |
Partyline Output Voltage: | 26 - 28VDC, 850mA per pair (A/B or C/D) |
Four-Wire/Matrix Connection: | 4 RJ-45 |
Program Input: | LR-3F, transformer isolated, line-level input |
Stage Announce Output: | XLR-3M, transformer isolated, line-level output |
Front Panel Headset: | 4-pin male and 5-pin female options |
Front Panel Displays: | 4 OLED’s with encoders and assignable soft keys |
Front Panel Indicators: | Antenna Status, Beltpack Status |
External Power Supply Connection: | 12VDC |
Base Station Programming/Editing: | Push-to-enter rotary encoder |
Dimensions | 1.75 x 19.0 x 10.2 in (HxWxD) (44 x 483 x 259 mm) |
Weight | 5.57 lbs (2.5 kg) |
What's Included
(1) FreeSpeak II Base II Base Station with 25 Licenses
(20) FreeSpeak II Digital Wireless Beltpacks
(20) Clear-Com CC-110 Single Ear Headsets (XLR4 Female)
(4) FreeSpeak II Active Antennas
(20) FreeSpeak II Lithium-Ion Batteries
(4) FreeSpeak II 5 Bay Chargers
(20) FreeSpeak II Digital Wireless Beltpacks
(20) Clear-Com CC-110 Single Ear Headsets (XLR4 Female)
(4) FreeSpeak II Active Antennas
(20) FreeSpeak II Lithium-Ion Batteries
(4) FreeSpeak II 5 Bay Chargers
