Vaxis Storm 3000DG Wireless Kit - G-Mount
Product Highlights:
- Up to 1080p60 Uncompressed Transmission
- 3000' Range, Less than 1 ms of latency
- SDI/HDMI Inputs, SDI Loop Output
- Dual SDI Outputs, HDMI Output
Vaxis Storm 3000DG Wireless Kit - G-Mount
Vaxis VS19-3000DG- TR02 Storm 3000DG Wireless Kit - G-Mount
The Storm 3000 from Vaxis features a 3000' range and supports up to 1080p60 uncompressed signal transmission with less than 1 ms of latency over the 5.1 to 5.9 GHz frequency. The transmitter features 3G-SDI and HDMI inputs plus a 3G-SDI loop output, and the receiver has dual 3G-SDI simultaneous outputs and an HDMI output. Both units come with V-mount battery plates. Both also support continuous power via 2-pin LEMO power inputs. Two D-Tap to LEMO cables are included. Other features include OLED displays, multicasting, timecode and metadata support, ARRI ALEXA Mini instant playback, and smart active cooling that allows for extended operation in hot environments. Both units are designed with a robust metal housing.
| Vaxis Storm 3000 3G-SDI & HDMI Wireless Transmission Kit Specs |
|---|
| Wireless Range |
3000' / 914.4 m (Line of Sight) |
| Channel Bandwidth |
40 MHz |
| Frequency Range |
5.1 to 5.9 GHz |
| Latency |
< 1 ms |
| Wireless Video Compression |
Uncompressed |
| Transmitter Antenna Ports |
2 x RP-SMA |
| Receiver Antentaa Ports |
5 x RP-SMA |
| Transmitter Video Connectors |
1 x BNC (3G-SDI / HD-SDI / SD-SDI) Input
1 x HDMI Input
1 x BNC (3G-SDI / HD-SDI / SD-SDI) Loop Output |
| Receiver Video Connectors |
2 x BNC (3G-SDI / HD-SDI / SD-SDI) Output
1 x HDMI Output |
| Video Format |
SDI / BNC
1080p at 23.98/24/30/50/59.94/60 fps
1080i at 50/59.94/60 fps
720p at 50/59.94/60 fps
576 at 60 fps
HDMI:
1080p at 23.98/24/50/59.94/60 fps
1080i at 50/59.94/60 fps
1080PsF at 23.98/24/25/29.97/30 fps
720p at 50/59.94/60 fps
576p at 60 fps |
| Timecode |
Yes |
| Transmitter Panel Type |
OLED |
| Transmitter Panel Type |
OLED |
| Transmitter Battery Support |
1 x V-Mount |
| Receiver Battery Support |
1 x V-Mount |
| Transmiter Power Connector |
1 x 2-Pin LEMO (6 to 36 VDC) Input |
| Receiver Power Connetor |
1 x 2-Pin LEMO (6 to 36 VDC) Input |
| Operating Temperature |
32 to 104°F / 0 to 40°C |
